Description
Function description
The fixed and rotating pattern discs, under the zoom lens, can project pattern effects from multiple angles. The beam angle can be adjusted through the zoom lens for enhanced flexibility. With the addition of a bi-directional rotating eight-prism, a six-row prism, double prism stacking, independent atomization effects, and electric focus, coupled with a linear CMY color mixing system, it provides rich and saturated light colors.
This is a high-performance moving head pattern light, meeting various coloring needs for different occasions. It is well-suited for entertainment venues such as bars, dance halls, nightclubs, and performances.
Parameters
|
Input Voltage |
100-240V, 50/60Hz
|
Output Voltage |
V1:48V:(LED driver) V2:36V(Master board), V2:12V(cooling fan+Display) |
|
Power supply |
600W
|
Light source |
450W module LED engine
|
|
Power consumption |
480W
|
LED temperature |
9000K |
|
CRI |
Standard:70CRI high :90CRI |
Dimming |
0-100% 16bit linear smooth dimming |
|
CMY |
Linear CMY color mixing |
CTO |
8500K-2800K |
|
Diamter of optic lens |
148mm |
Zoom angle |
3–50° |
|
Lifetime |
≥20,000Hours
|
Color wheel |
1 color wheel, 7fixed colors plus white |
|
Static gobo |
12 gobos plus 1 white circle
|
Rotation Gobo |
7 Gobo plus 1 white circle |
| Prism |
Equipped with 8 prism, and 6 rows prism, the two prisms can be stacked and rotated in both |
Frost | with smooth wash effect |
|
Control panel |
LCD Touch screen Overheating self-energy protection LED, extending LED life
|
Signal socket |
Standard 3 PIN XLR /5PIN XLR socket |
|
DMX Channel |
29CH
|
Operate mode |
DMX512, Auto, master/slave, RDM |
| Net Weight | 20.4kg |
Gross Weight |
23kg
|
|
Fixture size |
338*254*621mm |
Package size |
73*34*41cm/23kg (Carton)
72*42*84cm 66KG (Flight case 2 in 1） |
