Description
Built in a wether-defying housing, the DELUGEM19X60WFX features a powerful 19 x 60W RGBW LED source with 76 x 0.5W RGB Aura LEDs delivering exceptional brightness and rich colour mixing. Versatile colour capabilities are driven by the RGBW LEDs, providing seamless colour control across a wide spectrum. Dynamic effects include motorised zoom with an expansive range of 4.5° to 61°, individual pixel control for stunning visual mapping, and a dedicated Aura LED effect. Crucially, the fixture features a rotating front lens that creates a captivating split beam effect for dynamic, unique aerials and washes. Control options include 5-pin DMX, RDM, ArtNet, and sACN as well as RJ45 connection capabilities.
Specifications:
Photometrics
Light Source:
— 19 x 60W RGBW LEDs
— 76 x 0.5W RGB LEDS
Beam Angle: 4.5° – 61°
Output @3m: 145,200 lumen @ 10°; 5,203 lumen @ 61°
LED Lifespan: 50,000 hours
Effects
Dimming: 0-100%, 16 bit
Pixel Control: Yes
Aura LEDs Effects (RGB LEDs)
Strobe: Yes
Zoom: Motorised, 4.5° – 61°
Movement
Pan: 540°
Tilt: 205°
Power
Input Voltage: 100-240V AC, 50/60 Hz
Power consumption Max.: 1,500W
Connection: IP65 True1 in/out
Control
Operation Modes: DMX, auto, sound active, master/slave
Control Protocol: DMX, RDM, ArtNet, sACN
DMX Channels: 28 / 98 / 251 / 321
Control Interface: 5-pin DMX in/out, RJ45 in / out
Display: Full colour 180° reversible LCD control panel
Software upgrade via RJ45 cable
Housing
Housing Materials: ABS and steel, matte black finish
IP Rate: IP65
Size: 430 x 280 x 514 mm / 16.9″ x 11.0″ x 20.2″
Net Weight: 23 kg / 50.7 lbs
